Video Overview w/ Frank Klepacki & Face The Funk Terminated with locking 4 pin connector for A-T UniPak® body pack wireless transmitters. 1.4 m cable. Includes windscreens
Ideal for drummers, keyboard players or anyone requiring hands free operation
Comfortable, unobtrusive headband design with side of mouth pickup
Belt mounted power module operates on battery or phantom power
Cardioid polar pattern improves isolation of desired sound source
ELEMENT Fixed charge back plate, permanently polarized condenser
POLAR PATTERN Cardioid
FREQUENCY RESPONSE 40-15,000 Hz
LOW FREQUENCY ROLL-OFF 80 Hz, 18 dB/octave
OPEN CIRCUIT SENSITIVITY PHANTOM: -55 dB (1.7 mV) re 1V at 1 Pa
BATTERY: –56 dB (1.5 mV) re 1V at 1 Pa
IMPEDANCE PHANTOM: 200 ohms
BATTERY: 270 ohms
MAXIMUM INPUT SOUND LEVEL PHANTOM: 146 dB SPL, 1 kHz at 1% T.H.D.
BATTERY: 132 dB SPL, 1 kHz at 1% T.H.D.
DYNAMIC RANGE (typical) PHANTOM: 111 dB, 1 kHz at Max SPL
BATTERY: 97 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO 59 dB, 1 kHz at 1 Pa
PHANTOM POWER REQUIREMENTS 11-52V DC, 2 mA typical
BATTERY TYPE 1.5V AA/UM3
BATTERY CURRENT / LIFE 0.4 mA / 1200 hours typical (alkaline)
SWITCH Off, on flat, on roll off
WEIGHT (MICROPHONE) 31 g
WEIGHT (POWER MODULE) 139 g
DIMENSIONS (MICROPHONE) 10.0 mm diameter
DIMENSIONS (POWER MODULE) 84.0 mm H x 63.0 mm W x 22.0 mm D
DIMENSIONS (HEADSET) 165.0 mm nominal at widest point, 67.0 mm flexible boom
OUTPUT CONNECTOR (POWER MODULE) Integral 3 pin XLRM type
CABLE 1.4 m long (permanently attached to microphone), 2.6 mm diameter, 2 conductor shielded cable with TA3F type connector
ACCESSORIES FURNISHED AT8531 power module; AT8128 windscreen; AT8125 windscreen; battery windscreen; AT8125 windscreen; battery ACCESSORIES FURNISHED AT8531 power module; AT8128 windscreen; AT8125 windscreen; battery
