The BP40 broadcast vocal microphone offers a rich, natural, condenser-like sound from a large-diaphragm dynamic design. The large diaphragm features patented floating-edge construction that maximizes diaphragm surface area and optimizes overall diaphragm performance, while the humbucking voice coil prevents electromagnetic interference (EMI).
With rugged construction and stylish, waveform-inspired design, the BP40 delivers clear and articulate reproduction, ideal for any broadcast application. Optimized capsule placement helps maintain a commanding vocal presence even at a distance, while the multistage windscreen provides superior internal pop filtering. The BP40 broadcast microphone also includes a switchable 100 Hz high-pass filter to provide even more pop protection.
Rich, natural, condenser-like sound
Large diameter diaphragm with patented floating-edge construction for optimal diaphragm performance
Humbucking coil prevents electromagnetic interference (EMI)
Hypercardioid polar pattern improves isolation
Switchable 100 Hz high-pass filter
Superior off-axis rejection for maximum gain before feedback
Optimized capsule placement for commanding vocal presence even at a distance
Multistage windscreen provides superior internal pop filtering
Rugged, all-metal construction for dependable use in professional broadcast environments
ELEMENT Dynamic
POLAR PATTERN Hypercardioid
FREQUENCY RESPONSE 50-16,000 Hz
OPEN CIRCUIT SENSITIVITY –48 dB (3.9 mV) re 1V at 1 Pa
IMPEDANCE 450 ohms
SWITCHES Flat, roll-off
WEIGHT 632 g
DIMENSIONS 164.0 mm long, 56.0 mm diameter
OUTPUT CONNECTOR Integral 3-pin XLRM-type
ACCESSORIES FURNISHED AT8483 mounting clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch
AT8484 better Spider
OPTIONAL ACCESSORY: AT8484 shock mount for 5/8"-27 threaded stands OUTPUT CONNECTOR Integral 3-pin XLRM-type
ACCESSORIES FURNISHED AT8483 mounting clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch
AT8484 better Spider
OPTIONAL ACCESSORY: AT8484 shock mount for 5/8"-27 threaded stands stands
