Balanced AES/EBU Audio Digital cable (2 x 0,22 mm2) small diameter aluminium foil shielded flame resistant overall jacket. - O.F.C. (Oxygen Free Copper). Black colour
Priced and sold by the Metre
Technical Specifications
Application fields: Patch connections / gooseneck microphones / Home recording connections / Rack and console connections
Conductors: Bare copper - 24 AWG = 28 x 0,10 mm (0.22 mm2)
Insulation: PE Ø 1.20 mm
Shield: Aluminium foil 100%%
Jacket: Flame resistant PVC 70 shore Diameter 3.00 mm - Complying with CEI 20-22 II regulations
Colour: Black
Drain wire: Tinned copper 25 AWG = 7 x 0.18 mm (0.18 mm2)
Electrical resistance: 87 Ohm/Km (conductor) @ 20°C
Electrical capacitance:
37 pF/m (conductor/conductor) @ 1 KHz
57 pF/m (conductor/shield) @ 1 KHz
Nominal impedance: 110 Ohm
Velocity of propagation: 80 %
Operating temperature: -20°C / +70°C
Working tension:
< 50 V AC
< 75 V DC
Weight: 10 Kg/Km
Minumum bending radius: 20 x cable section radius
Packaging: 100 metre carton reel
