Features
Digital 24-bit/48 kHz wireless operation for ultimate sound quality and dependable performance
Plug and play operation in the 2.4 GHz range – completely free from TV interference
User can switch between Standard mode (10 channels) and HD mode (20 channels) to minimize latency or maximize channel count, respectively
Receiver units can be docked in the chassis or mounted remotely (up to 328 feet away) via Ethernet cable for added versatility
Up to five chassis can be linked and used simultaneously
Each receiver channel can be paired with up to four transmitters, allowing users to instantly switch between different transmitter configurations
Chassis’ System ID Display shows RF signal level, system ID, transmitter battery level, and system link status
Each half rack receiver chassis comes with a short and a long rack ear, and two long ears can be combined as a joining plate to secure two chassis in a full rack space
Compatible with Audio-Technica’s Wireless Manager software for centralized management of system settings and operations
Auto lock function prevents unintended operations like turning off the power or displaying the channel select screen
AES128 encryption for security
Compatible with Syslog protocol
Ability to configure, monitor, and save device settings as projects in Wireless Manager
Transmitters and receivers include OLED screens for optimal readout of key settings and alerts
Water and sweat resistant cW-style connector on bodypack transmitter provides secure connection to lavalier mics, headworn mics, and cables with cW-style locking 4 pin connector
Charging terminals on bodypack and handheld transmitters work with ATW-CHG3/ATW-CHG3a and ATW-CHG3N/ATW-CHG3Na charging docks to recharge NiMH batteries
Supports mixed output for situations with limited input channels
Specifications
Overall System
Operating Frequencies 2,402 to 2,480 MHz
Dynamic Range 120 dB (A-weighted), typical
Total Harmonic Distortion < 0.05%, typical
Maximum Simultaneous Use (recommended) Standard: 10 channels HD mode: 20 channels
It depends on the region and environment.
System Frequency Response 20 to 20,000 Hz
Varies depending on the microphone to be installed.
Delay Standard: 2.8ms
HD mode: 6.7ms
Audio Sampling Rate Standard: 24-bit/48 kHz
HD mode: 24-bit/48 kHz
Encryption Method AES128 Encryption Method AES128
