Channels 2 + 1
EQ 3-band: +6dBu / Total Kill (CH 1 & 2)
High Frequency 3.5kHz
Mid Frequency: 1.1kHz
Low Frequency: 500Hz
2-band: +/- 12dBu (AUX CH)
High Frequency 900Hz
Low Frequency: 750Hz
Line Inputs 3 x RCA (CH 1 & 2 + Aux CH)
Phono Inputs 2 x RCA (CH 1& 2)
Mic Input 1 x Combi (XLR + TRS)
Master Output 1 x XLR (Balanced)
Booth Output 1 x RCA (Un-balanced)
Record Output 1 x RCA (Un-balanced)
Master Insert 1 x RCA MASTER INSERT FX Loop*
*Send/Return I/O 1 x RCA MASTER INSERT Send
1 x RCA MASTER INSERT Return
*FX Send 1 x Master Insert IN
Filter 1 x Voltage Controlled Filter
HPF / LPF
Adjustable Frequency & Resonance
Assignable CH 1 & 2 + Aux CH
Headphones 1 x 1/4"
1 x 3.5mm
Split Cue Monitoring
Channel Faders 45mm Voltage Controlled Amplier
Chanel Meters Single tri-colour LED
Mix Meters 12 LED
X-Fader 45mm VCA mini innoFADER®
X-Fader Curve Settings 2 Types (Fast-cut/Blend)
Earth Ground Terminals x 1
Headroom +18dB
DC Mains 100 to 240V
AC 50/60Hz
Consumption 35W max
Mains Adaptor 2 pin DC socket with cable clamp
