USB
· Port type USB-C
· USB host USB 2.0 Full Speed (12Mbps)
X:Link
· Port type RJ45 x 2 IN + OUT Full-duplex ¦ Data only
Hardware Controls
· Potentiometers 12 270° rotation
· Faders 4 60mm linear faders
· Endless encoders 6 with push switch
· Tactile switches 30 with RGB LED feedback
· RGB LEDs 34 16 colour palette
MIDI Controls 174 Total
Defaults QTY Range
· MIDI Channels 16 1-16
· Control Change – absolute 16 0-127
· Control Change – relative 6 127/1
· Note ON/Note OFF 36 127/0
Power Requirement
· USB host 5V, 450mA max
Power Consumption max, per device
· USB host 450mA @ 5V = 2.25W
· XLINK host 450mA @ 5V = 2.25W
Dimensions
Unpacked
· Height 49.5mm 2”
· Width 135 mm 5.3”
· Depth 358 mm 14.1”
Packed
· Height 85 mm 3.4”
· Width 190 mm 7.5”
· Depth 445 mm 17.5”
Weight (unpacked) 1.25kg 2.2 lbs
Weight (packed) 1.6 kg 3.5 lbs
